Flat bed hot stamping module

• National Invention patented 90° rotatable hot stamping head
• National Invention patented flat bed pressing technology
• Servo driven control for saving, upgradable to registered holographic embossing.
• Along Web and cross web direction hot foil stamping

Full-Rotary Flexo Unit

• Servo driven tension control, quick removal of ink cassette, easy mounting of doctor blade
• Multi-function flexo unit for laminating, varnishing, cold foil or printing.

Semi-Rotary Flexo Unit

• Fast and easily changing for semi-rotary and full-rotary, suitable for UV spot varnishing
• Optional hot air dryer for water base priming or varnishing.

Semi-Rotary Die Cutting Unit

• Servo driven tension control
• Magnetic cylinder or solid cylinder

Moveable Touch Screen

• Operator friendly, maximize operation efficiency

Slitting Unit

• Stable and accurate slitting
• Optional shear knife slitting or razor blade slitting.

Optional Rotary Silkscreen Unit
Optional Delam and Relam / Turn Bar
Optional Laser die cutting unit
Optional Flat Bed Screen Printing
Optional Flat Bed Die Cutting

Model	SDF330	SDF420	SDF520
Max. Web Width	340mm	430mm	530mm
Max. Unwind Diameter	800mm	800mm	800 mm
Max. Rewind Diameter	600mm	600mm	600 mm
Max. Die Cutting Width	330mm	420mm	520 mm
Semi-rotary Max. Speed	50 m/min	50 m/min	50  m/min
Semi-Rotary Max. Repeat Length	457mm	457mm	457 mm
Flat Bed Die Cutting Max. Mechanical Speed	120m/min	120m/min	120 m/min
Die Cutting Tolerance	±0.15mm	±0.15mm	±0.15 mm
Air Supply	8bar	8bar	8 bar
Rating Voltage	3PH+ N+ PE	3PH+ N+ PE	3 PH+ N+ PE
